P-P6P38-K3R0 | Panel Interface Connector

Panel Interface Connector with Monitor; HDMI female to female; Panel Mount Housing; UL Type 4; Simplex Outlet; No Circuit Breaker

Web Price

Regular price: $463.00
Sale price: $463.00

Quantity

Quantity must be 1 or more

FIND DISTRIBUTORS Datasheet

Product Details

Product Specifications
- Product Description
  - Panel Interface Connector that typically mounts to the outside of a control panel housing. These programming ports eliminate the need to open the panel door and improve safety and compliance to NFPA 70e. We offer 15,000+ combinations of components and outlets.
- Component Details
  - Component Code P6
  - Component Quantity 1
  - Component Description VGA Monitor
  - Component Type Cable
  - Gender Front HDDB15 Female
  - Gender Back HDDB15 Male
  - Component Code P38
  - Component Quantity 1
  - Component Description USB Type A-A F/F
  - Component Type Bulkhead
  - Gender Front USB A-Female
  - Gender Back USB A-Female
- Electrical Specifications
  - Power Type Domestic Simplex Outlet
  - Power VAC 120
  - Power AMPs 15
  - SCCR Rating 10kA
- Mechanical Specifications
  - Enclosure Rating IP65
  - Housing Size K Size Housing
  - UL Type Type 4
  - Latch Type 304 Stainless Steel
  - Cover Polycarbonate, UV rated
- Geometric Data
  - Width 5.08 in
  - Height 3.54 in
  - Depth 1.60 in
- Commercial Data
  - Country of Origin US
  - Schedule B Code 8537.10.9090
